    High Speed Automatic Plastic Lamination Machine PE Foam Sheet Laminating Machine

    Jiangsu Laiyi designs and manufactures extrusion laminating/coating lines on the strength of a thorough expertise in the co-extrusion of special polymers - customized and modular layout to meet the demand for special products; - chill-roll unit with precise temperature control - rapid cooling system - special winders and unwinders suitable for any final application.

    Jiangsu Laiyi extrusion and co-extrusion units at the forefront of technology, boasting a high manufacturing quality with components suitable for processing also corrosive polymers. we has focused on high performance extruders with special screw design for a wide range of materials like LDPE, SURLYN, EVA, EAA, PP, with customized solutions including different layers, sizes and die widths.

    一, Thermal Film Extrusion Laminating Machine

    • Thermal film is used to BOPP thermal film, PET pre-coated film
    • We also make customized machine.

    二,Technical parameters of Thermal film extrusion laminating machine

    Machine width1700mm/2150mm/2350mm
    Effective widthMax1600mm/2000mm/2200mm
    Machine speed250-300m/min
    Screw diameterΦ90mm/Φ100mm/Φ115mm
    Extruder outputMax 250kg/h /300kg/h/450kg/h
    ResinsEVA
    Coating thickness5-45μm
    Max unwinder and rewinder diameterΦ800mm
    Basic materialPlastic film

    三, Main Features of laminating machine

    1) Double Shaft-less paper roll stands suitable for 3-6 inch paper core,automatic lift ,easier operation .

    2) Auto splicer device realize paper in 150-300 m/min speed exchange without decrease machine line speed

    3) Ultrasonic type EPC system,makes frequent replacement materials operation more simple

    4) Hydraulic lamination structure design , can make coating thinner and firm .

    5) Trimming device make the finished coated paper rolls even

    6)Special cutting knife and rewinder design makes high speed rewinding shafts exchange possible


    Bead cut equipment

    • Shrink-width makes two sides thicker, as a result, the two sides of the composite material need to be trimmed, otherwise the composite material will have some quality problems such as drape, crimp and unevenness.
    • It is convenient to renew cutter and adjust effective width. It can save time and labor at the same time, and makes the products flat and smooth.
