    Double Sided 4mm Alloy Steel Paper Laminating Machine LDPE Resins

    Ask Lasest Price
    Brand Name : LAIYI
    Model Number : ASRP/ADRP
    Certification : CE , ISO9001
    Price : $90,000--$450,000/set
    Payment Terms : T/T, , L/C
    Supply Ability : 20sets/month
    Delivery Time : 5 months
    • Product Details
    • Company Profile

    Double Sided 4mm Alloy Steel Paper Laminating Machine LDPE Resins

    Jiangsu Laiyi has been highly recognized and praised in domestic extrusion laminating industry since 2007 and has increasing market share.

    As more and more cooperation relationships with foreign enterprises, Jiangsu Laiyi has established a good reputation in the international market.

    Jiangsu Laiyi is working on becoming one of the first class packing machinery manufacturers in the world by our professional quality and superior service

    Professional extrusion laminating line established by more than 10 years of working can provide long time services for large enterprises both at home and abroad with professional researches.

    As a domestic normalized packing machinery manufacturer with strength, who has develpment and technical force, and solid manufactruing and service system, Jiangsu Laiyi has sold more than 600 sets of machines in the world.


    Specification of Release Paper Extrusion Laminating Machine :


    ItemLY-ASRP-1200LY-ASPR-1400LY-ASRP-1700
    LY-ADRP-1200LY-ADRP-1400LY-ADRP-1700
    Effective laminating width:max1100mmmax1300mmmax1600mm
    Machinery speed:300-350m/min300-350m/min300-350m/min
    Screw diameter:φ90mmφ100mmφ115mm
    Max unwinder diameter:φ1200mmφ1200mmφ1200mm
    Max rewinder diameter:φ1200mmφ1200mmφ1200mm
    Max output:300kg/h,400kg/h or 550kg/h
    Resins:LLDPE/LDPE/PP/EVA
    Laminating thickness range:8-45μm
    Base material:Paper(35-200gsm)
    Water supplier temperature:15°-25°
    Power supply:380V-50Hz (3-phase 5-wire)

    • Two original paper rolls can be installed at the same time on the shaftless unwinder.
    • Auto-splicing is controlled by computer and can be done without stopping the line.
    • Web-guide device ensures that the paper/paper board passes uniformly and neatly.
    • Bead cutter for edge trimming.
    • Corona treatment on the surface of paper is to increase the peeling strength of PE and paper.
    • Rewinder consists of rewinding stand, tension control system, splicing device and towing device.
    • Tension control system is to ensure the constant tension of rewinding.

    Double station unwinder:

    • It applies to multiple materials and has a wide range of us.
    • It can automatically change rolls without stopping machine or reduce speed.
    • It has one-button and no-button type operation, is simple and conveniet.
    • It occupies small area, can save the production spaces.

    Double Sided 4mm Alloy Steel Paper Laminating Machine LDPE Resins


    " Professional qualifications to create brand" is Laiyi's business objective!


    "Create excellece by quality, prvide service with honesty" is


    Laiyi's business prupose!
